Driving robot Discovery
Home
Blog
Robotics

Discovery: a robot on wheels using the ARMv7-based fischertechnik TXT controller running embedded Linux.

You can view the pictures and video of the construction and then continue with the latest blog entry
OR
You can click here to go directly to the latest blog entry.

Please support this blog by making a (small) donation via paypal or wired.
OR become a patron and have your name mentioned.

1: The box 2: ...and its contents.. 3: Login via ssh at the TXT 3: Some system information
1: 2: 3: 4:

This system information clearly shows it is running the 3.16.1 kernel and the TXT is ARMv7l based. The free command shows that the TXT has 240 MB RAM and df -k shows the internal storage capacity is about 107MB large. Further searching reveals that there are .wav audio files present, but nothing else. So it has to be programmed before use.

1:TXT USB camera 2:The controller with camera attached: most left connector 3:Screenshot of dmesg command-output.
1: 2: 3:

Next test is to connect the USB camera to the TXT controller. The screenshot shows that the camera registered in Linux. It also shows that the manufacturer of the camera is Sonix. Next, it shows that the camera also contains either a speaker or a microphone: snd-usb-audio. The output ends with a g_ether_gadget, which actually is the controller itself.
Here is a short video on the controller. The laptop it is connected to is running an old Pentium M. This shows again that you don't need fancy computers to run nice stuff.
Picture taken by the USB camera using an imagestream and a snapshot:

Small testing circuit using light transistor, lamp, buzzer and pulse motor. See blog of 10 July 2015:


The wheelbase as constructed from the manual:
1:Overview of the wheelbase. 2:Sideview of the wheelbase 3:Bottomview of the wheelbase. 4:Wheelbase with camera.
1: 2: 3: 4:

Playlist of all available riding robot Discovery videos.
